EAN:
SKU: PSC260 Solar Tire Pressure Sensor 300mAh 4.0/5.0 Bluetooth Sensing Monitoring TPMS433.92Mhz External Tire Pressure Sensor 4 Wheel Car/Motoring Car/Truck/Project Car/Tructor Tire Pressure Sensor LCD Solar Digital Clock/Time/DATE and Internal Temperature Car Tire Pressure Control Safety Alarm Car Tire Pressure Sensor Real-time Monitoring High Tire Pressure Low Tire Pressure
Product description
Sales components: solar monitoring monitor + tire pressure sensor
Mounting type: external tire pressure sensor
Material of the product: ABS+
Product color: black
Solar monitors
Lithium battery capacity: 300mAh
Operating voltage: 3.7-5V
Bluetooth communication: 4.0/5.0
DISPLAYED BY: APP
Color display: LCD
Pressure range: 0-8bar / 0-116psi
Operating frequency: 433.92MHz±20.00MHz
Working pressure: 0-99 pounds/square inch
Operating current: ≤6 mAh (bright); ≤4 mAh (black)
Main chip: DA14531
Operating temperature: -30°C-85°C
Storage temperature: -30°C-90°C
Charging method: solar energy + USB
Tire pressure sensor
Battery life: 24 months
Operating voltage: 2.1-3.6V
Storage temperature: -30°C-90°C
Operating temperature: -30°C-85°C
Temperature resolution: ±2°C (25°C)
Pressure range: 0-3.5 bar
Pressure resolution: ±0.1 bar
Response time: ≤5s
Maximum pressure: 8BAr
Pressure accuracy: ±0.1bar / ±1.5psi
Waterproof rating: IP67
Transmission power: ≤10 decibels
Transmission frequency: 433.92 MHz
Tire pressure monitoring range: 0-3.5bar
Accuracy of tire pressure monitoring: 10kPa
Coin cell battery: CR1632 (removable replacement)
Service life: 1-2 years typical value
Power supply method: OBD, ACC, USB
Product certification: CE FCC ROHS UKCA
Commodity characteristics
1. Solar and USB dual charging, LCD color display, automatic brightness adjustment
2. Monitor tire pressure and temperature in real time, and 4 tire data are displayed at the same time.
3. Wireless transmission technology, 100% DIY installation
4. Built-in rechargeable and explosion-proof lithium battery, Panasonic CR1632
5. G-sensor vibration wake-up, solution: Infineon
6. Support 'BAR' ' 'PSI' units are optional
7. Wireless displays can be placed anywhere.
8. Original chip (more stable signal)
9. Tire pressure alarm (real-time monitoring)
10. Tire temperature alarm (real-time monitoring)
11. Solar charging (reducing energy consumption)
12. Wireless transmission (simple installation)
13. The first adjustable screen angle
Keyword
Light trucks, medium trucks, heavy trucks;
Peterbilt Peterbilt, Kenworth, Flena, Western Star, Mark Truck, Ford Racing, Soelle Truck, Belas Truck, Mining Truck, West Stanska, Kamas Truck, Universal Truck, Will Smith Motorhome;
Mercedes-Benz truck, Scania, Volvo truck, Mann, Iveco, Renault truck, Duff, Auman truck;
Karen Binwei KLEN.RV, off-road RV, Forest River RV, Mercedes-Benz RV, Iveco RV;
Solar monitoring monitor + repeater + tire pressure sensor:
4 wheels, 6 wheels, 8 wheels, 10 wheels, 18 wheels, 22 wheels, 24 wheels, 26 wheels, 52 wheels, 62 wheels
Motorcycle tire pressure sensor, Bluetooth tire pressure monitor, car tire pressure monitor, tire abnormal alarm, air compressor and inflatable machine, fender and splash cover, tire maintenance, tire cover, tire pressure gauge, tire pressure monitoring system, monitoring tire pressure sensor, valve rod and valve cover, tire repair kit, tire repair tool, hub bearing, wheel positioning and balance, wheel accessories, tire accessories, tire accessories, tire and wheel maintenance, automobile tire pressure digital instrument, automobile, bus, truck, tractor, tractor, bicycle, motorcycle tire pressure detection tool, airbag scanning tool and simulator, battery tester, code reader and scanning tool, electrical tester and test lead, emission analyzer, fuel pressure tester, gas analyzer, ignition tester, laboratory oscilloscope, mechanical tester, multimeter and vacuum tester, pressure and vacuum tester
Packaging information
Product size: 14*13.5*5cm
Package size: 20.5*13.8*5.2mm
Net quantity: 245g
Gross product weight: 378g
